Coal Fired Boiler
Capacity: 1.2-42 Million Kcal
Applicable Fuels: coal
Application Industries: Petroleum, Chemical, Pharmaceutical,etc.
Xianchuang's biomass boilers are divided into YLW-S series coal fired thermal oil boilers, SHL solid fuel coal/wood fired steam boiler
For more information about this boiler model, please contact us !
 | ① Multi-circuit coil The flue gas heating surface is sufficient, and the contact time is long. |
② Partition wall Good flue gas isolation effect, reducing heat loss. | |
③ Ash removal door Convenient for personnel to perform maintenance, operation, and cleaning. | |
| ④ Combustion chamber Wide fuel adaptability, suitable for bituminous coal, anthracite, biomass pellets, etc. | |
⑤ Speed control box Reasonable speed designed according to fuel characteristics to ensure complete combustion. | |
| Note:This boiler body structure diagram uses the YLW biomass thermal oil boiler as an example. |
①Tailored environmental configurations ②Wide Fuel Adaptability Suitable for bituminous coal, anthracite coal, various biomass pellets, wood chips and other fuels. ③Efficient combustion The boiler's grate can be tailored to different types of coal, so that coal, air and heat can be fully mixed without flameout. ④Modular Transport & Installation The transportation and installation are fast, economical and stable, regardless of the road width and height limits. |
|
| Model | YLW-1400S | YLW-1800S | YLW-2400S | YLW-2800S | YLW-3500S | YLW-4200S | YLW-4600S | |
| Rated thermal power | MW | 1.4 | 1.8 | 2.4 | 2.8 | 3.5 | 4.2 | 4.6 |
| x10⁴ kal/h | 120 | 160 | 160 | 240 | 240 | 360 | 400 | |
| Rated outlet temperature | (℃) | 320 | 320 | 320 | 320 | 320 | 320 | 320 |
| Rated working pressure | (MPA) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Heat Efficiency | (≥%) | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 |
| System installed capacity | (KW) | 55 | 63 | 76 | 86 | 105 | 125 | 155 |
| Min. transport dimension | Length(MM) | 5000 | 5600 | 6500 | 6500 | 7500 | 7400 | 8000 |
| Width(MM) | 2250 | 2250 | 2500 | 2550 | 2550 | 2870 | 2820 | |
| Height(MM) | 2450 | 2750 | 2800 | 3200 | 3200 | 3300 | 3350 | |
| Max. transportation weight | (KG) | 11000 | 12700 | 13500 | 14500 | 16500 | 25500 | 29000 |
| Model | YLW-6000S | YLW-7000S | YLW-8200S | YLW-9400S | YLW-10500S | YLW-12000S | YLW-14000S | |
| Rated thermal power | MW | 6 | 7 | 8.2 | 9.4 | 1.5 | 12 | 14 |
| x10⁴ kal/h | 500 | 600 | 700 | 800 | 900 | 1000 | 1200 | |
| Rated outlet temperature | (℃) | 320 | 320 | 320 | 320 | 320 | 320 | 320 |
| Rated working pressure | (MPA) | 1 | 1 | 1 | 10 | 1 | 1 | 1 |
| Heat Efficiency | (≥%) | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 |
| System installed capacity | (KW) | 170 | 193 | 150 | 160 | 160 | 260 | 320 |
| Min. transport dimension | Length(MM) | 8320 | 9000 | 9760 | 9760 | 10500 | 11200 | 10500 |
| Width(MM) | 3330 | 3330 | 3270 | 3500 | 3500 | 3560 | 4000 | |
| Height(MM) | 3250 | 3350 | 4010 | 4010 | 4010 | 4010 | 3500 | |
| Max. transportation weight | (KG) | 33500 | 36000 | 35000 | 24800 | 25000 | 27500 | 31000 |
Note: This table displays parameters for YLW Biomass Fired Thermal Oil Boiler. For other models of thermal oil boilers, please navigate to the corresponding webpage or contact customer service.
